Guy strain InsulatorGuy strain InsulatorGuy strain Insulator

Guy strain Insulator

  • Guy strain Insulator are manufactured and tested to the requirements of ANSI Standard C29.4
  • Color:brown and gray

MAIN DIMENSTIONS AND STANDARD PARTICULARS

ANSI

CLASS

Fig.No

Leakage distance

mm

 Mechanical failing load

KN

Power-frequency flashover voltage

kV

Weight

(N)

Dry

Wet

54-1

1

41

44

25

12

4.9

54-2

2

47.6

53

30

15

7.8

54-3

3

57

89

35

18

12.3

54-4

4

76

89

40

23

17.6



MAIN DIMENSTIONS AND STANDARD PARTICULARS

AS Type

Type

Fig.No

Power-frequency wet withstand voltage

kV

Stand or wire rope size mm

Mechanical failing load

 KN

GY-1

J-2.7

5

10

7/2.75

27

GY-2

J-7

6

15

19/2.00

71

GY-3

J-16

7

20

19/2.75

222

GY-4

J-16B

8

30

19/2.75

222
